Why change from a lead-acid battery to a lithium battery?

Charging the battery

Lead Acid battery: The charging efficiency of this type of battery is low – only 75%! A lead-acid battery needs more energy for recharging than it delivers. The excess energy is used for gasification and for mixing the acid internally. This process warms up the battery and evaporates the water inside, which results in the need to top up the battery with distilled (demineralised) water.

Lead-acid recharging has severe limitations and a number of critical points. Here are the most important ones:

• Fast or partial charges ruin a lead-acid battery
• Charging times are long:  from 6 to 8 hours
• The charger does not collect full information on the battery. It only checks the voltage, and that’s not enough. Changes in temperature affect the recharge profile, so if the temperature is not measured, the battery will never charge completely in winter and will gasify too much in summer
  An incorrect charger or setting reduces battery life
• Poor maintenance will also reduce battery life

Lithium ion battery: Lithium-ion batteries can be “fast” charged to 100% of capacity.

A lithium battery saves on your electric bill, as it is up to 96% efficient and accepts both partial and rapid charging.

A lithium battery can be charged to 50% capacity in only 25 minutes.

This innovative characteristic enables our customers to equip their devices with lower installed battery capacity than the capacity required with lead-acid batteries, because lithium batteries can be recharged repeatedly over a short time

Electronic systems inside the battery control the charger effectively, so it can deliver the exact current that is consistent with internal parameters (voltage, temperature, charge level, etc …). If a customer connects an unsuitable battery charger, the battery will not activate and is thus fully protected.

Weight of battery

Lead Acid battery: 30Kg for kWh

Lithium ion battery: 6Kg for kWh

On average Lithium-Ion batteries weight 5 times less than standard lead acid battery.

Maintenance

Lead acid battery: high maintenance and systems costs. Ordinary maintenance is one of the greatest costs, as it includes topping up the water, maintaining the filling system, and removing oxide from the elements and terminals.

It would be a serious mistake not to take into consideration 3 other, hidden costs:

Infrastructure cost: lead-acid batteries release gas while they are charging and must therefore be charged in a dedicated area. What is the cost of this space, which could be used for other purposes? Cost of gas disposal: the gas released by lead-acid batteries must not remain inside the charging area. It must be removed to the outside by special ventilation systems. Cost of water demineralisation: in smaller companies, this cost can be included in ordinary maintenance, but becomes a separate expense for medium to large companies. Demineralisation is a necessary treatment for water used to top-up lead-acid batteries.

Lithium ion battery: no infrastructure cost, no gas and no need for water, which eliminates all additional costs. The battery just works.

Service life

Lithium-ion batteries last 3-4 times longer than lead-acid batteries, without losing effectiveness over time.

Safety, waterproofing and emissions

Lead acid batteries have no safety devices, are not sealed, and release hydrogen during charging. In fact, their use in the food industry is not permitted (except for “gel” versions, which are even less efficient).

Lithium batteries release no emissions, are suitable for all applications (also available in IP67) and feature 3 different control systems that protect the battery:

1. Automatic disconnection, which disconnects the battery when the machine/vehicle is idle and protects the battery from improper use by the customer

2. Balancing and management system which maximizes battery efficiency

3. Remote control system with automatic warning of troubles and malfunctions

This is just one of the many questions that our customers ask during our consulting service. Having the answer ready means saving valuable time that can be used for designing and producing batteries.
